PRINTPAY

Endpoint overview

All endpoints use your current host with the fixed /api/ base path.

Operation	Method	Purpose
STK Push	POST	Initiate a customer payment prompt.
Check status	GET	Check a transaction's status.
Callback	POST	Receive payment notifications.

Authentication

Keep your merchant API key private and make payment requests from your server.

Field	Type	Location	Purpose
`x_api_key`	String	STK Push request body	Authenticates your merchant account.

Do not place production API keys in frontend JavaScript, public repositories, or client apps. Load the key from a secure server-side environment variable.

Initiate an STK Push

Ask the customer to authorize a payment on their phone.

A successful initiation response only means the request was accepted. Confirm the final payment result through the status endpoint or a verified callback.

POST

Parameter	Type	Required	Description
`x_api_key`	String	Yes	Your merchant API key.
`phone_number`	String	Yes	Customer phone number, e.g. `0712345678` or `254712345678`.
`amount`	Integer	Yes	Payment amount in KES.

<?php
$url = "https://printpay.co.ke.helapull.com/api/stk_push";

$payload = [
    'x_api_key'    => getenv('PRINTPAY_API_KEY'),
    'phone_number' => '0712345678',
    'amount'       => 10,
];

$ch = curl_init($url);
curl_setopt_array($ch, [
    CURLOPT_POST           => true,
    CURLOPT_POSTFIELDS     => http_build_query($payload),
    CURLOPT_RETURNTRANSFER => true,
    CURLOPT_CONNECTTIMEOUT => 10,
    CURLOPT_TIMEOUT        => 30,
]);

$response = curl_exec($ch);

if ($response === false) {
    throw new RuntimeException(curl_error($ch));
}

curl_close($ch);
echo $response;
?>

const axios = require('axios');

const url = "https://printpay.co.ke.helapull.com/api/stk_push";

axios.post(url, new URLSearchParams({
  x_api_key: process.env.PRINTPAY_API_KEY,
  phone_number: '0712345678',
  amount: '10'
}).toString(), {
  headers: { 'Content-Type': 'application/x-www-form-urlencoded' },
  timeout: 30000
})
.then(response => console.log(response.data))
.catch(error => console.error(error.response?.data || error.message));

import os
import requests

url = "https://printpay.co.ke.helapull.com/api/stk_push"
payload = {
    "x_api_key": os.environ["PRINTPAY_API_KEY"],
    "phone_number": "0712345678",
    "amount": 10
}

response = requests.post(url, data=payload, timeout=30)
response.raise_for_status()
print(response.json())

curl --request POST \
  "https://printpay.co.ke.helapull.com/api/stk_push" \
  --header "Content-Type: application/x-www-form-urlencoded" \
  --data-urlencode "x_api_key=$PRINTPAY_API_KEY" \
  --data-urlencode "phone_number=0712345678" \
  --data-urlencode "amount=10"

Example initiation response: {"status":"success","checkout_id":"ws_CO_..."}. Use the actual response fields returned by your API.

Check transaction status

Use the checkout ID returned by the STK Push request.

GET

Query parameter: check_status. Respect your API's rate limits when polling.

<?php
$checkoutId = 'ws_CO_070720261234567890';

$url = "https://printpay.co.ke.helapull.com/api/stk_push?check_status="    . rawurlencode($checkoutId);

$ch = curl_init($url);
curl_setopt_array($ch, [
    CURLOPT_RETURNTRANSFER => true,
    CURLOPT_CONNECTTIMEOUT => 10,
    CURLOPT_TIMEOUT        => 30,
]);

$response = curl_exec($ch);

if ($response === false) {
    throw new RuntimeException(curl_error($ch));
}

curl_close($ch);
echo $response;
?>

const axios = require('axios');

const url = "https://printpay.co.ke.helapull.com/api/stk_push";

axios.get(url, {
  params: { check_status: 'ws_CO_070720261234567890' },
  timeout: 30000
})
.then(response => console.log(response.data))
.catch(error => console.error(error.response?.data || error.message));

import requests

url = "https://printpay.co.ke.helapull.com/api/stk_push"
response = requests.get(
    url,
    params={"check_status": "ws_CO_070720261234567890"},
    timeout=30
)
response.raise_for_status()
print(response.json())

curl --get \
  "https://printpay.co.ke.helapull.com/api/stk_push" \
  --data-urlencode "check_status=ws_CO_070720261234567890"

Successful payment

{
  "id": "241",
  "status": "SUCCESS",
  "phone_number": "254712345678",
  "amount": "10.00",
  "mpesa_receipt_number": "TGR7XYZ890"
}

Pending payment

{
  "id": "241",
  "status": "PENDING",
  "phone_number": "254712345678",
  "amount": "10.00",
  "mpesa_receipt_number": null
}

Callback notifications

Receive transaction updates at your configured callback URL.

Configure your callback URL in the relevant merchant settings. Confirm the callback method, payload, and registration requirements against your deployed API.

POST

{
  "checkout_id": "ws_CO_070720261234567890",
  "status": "SUCCESS",
  "mpesa_receipt": "TGR7XYZ890",
  "amount": 10.00,
  "phone": "254712345678",
  "result_code": 0
}

Treat this as an illustrative payload only. Verify callback authenticity, validate amount and receipt, and update transactions idempotently before fulfilling an order.

Common result codes

Example meanings often seen in M-Pesa STK integrations.

Code	Status	Typical meaning
`0`	SUCCESS	Transaction reported as successful. Verify receipt and amount before fulfilling an order.
`1032`	FAILED	Commonly associated with a customer-cancelled STK request.
`1037`	FAILED / TIMEOUT	Commonly associated with a request timeout or unreachable handset.
`2001`	FAILED	Commonly associated with an invalid or rejected customer PIN.

Confirm result-code meanings against the Safaricom and Printpay API versions you use. The deployed gateway's documentation is authoritative.
